New style auto darkening welding mask A5002
Art. No.: A-5002
Technical specification:
| Cartridge Size | 110*90*9mm |
| Viewing Area | 100*41mm |
| Arc Sensor | 2 |
| Light State | DIN4 |
| Shade State | DIN9-13 Outside Variable |
| Grinding Function | Yes, DIN4(Outside) |
| Sensitivity | Stepless Adjustable(Inside) |
| UV/IR Protection | Up To Shade DIN 16 at all time |
| Switching Time | <0.1ms( Room Temperature) |
| Delay Time | 0.1-1.0S(Inside Stepless Adjustable) |
| Power Supply | Solar Cell&Li-Batteries,No Battery change required |
| TIG Rating | Enhanced |
| Operating Temp | -10° C~+60° C |
| Mask Material | Nylon(PA) |
| Total Weight | 475g |
| Warranty | 2 years |
| Approved | EN379:2009,EN175:1997;CE,ECS(1883) |
-------------------------------------------------------------------------------------------------------------------------------------------
Welding mask Description:
1. Impact-resistant shell, PP material
2. View area size: 108mm x 50mm
3.Wheel ratchet harness with soft foam head pad , comfortable to wear, protect face and head from hurt by spark
4. flip-up front design, perfect in workmanship . Easy to change the glass, shell can be repeated to use 5. Adapt for welding, cutting, gas cutting, etc. 6. The protective lens made with high technology can instantly become dark while receiving rays, so effectively protect users eyes; its darkness can be adjusted from No. 9 to No. 13 as your requirement. 7. can print ,stick or emboss customized LOGO. 8.Packing: One piece per polybag, 30 pcs per carton. 9.Delivery time: 30 days after receiving the 30% deposit. Auto darkening welding mask Characteristic:
Our Auto Darkening Welding Helmet is designed and manufactured strictly according to the EN standard.
They are in full comformity with CE -EN 379:2009 and EN175:1997.
1)Material & Decal
Made from a high impact polyamide nylon material which ensures the helmet to provide high level of comfort
and durability.
The mask has been approved CE EN175, It is suitable for a variety of attractive decals.
2)Filters Feature
The auto darkening ,wide view lens switches from light to dark in 0.1 ms,and offers continuous eye protection
against UV and IR radiation,even when the filter is in the light state mode.
-The grinding switch is conveniently located on the outside of the helmet and the switch locks the filter in the
light state(Shade DIN4) to enable the helmet to be used as a grinding visor.
-The helmet is powered by a solar cell and there is no need for external Li-batteries.
The internal battery life expectancy is over 6 years.
